RUKO GmbH sovitin KEB Quick-In sisäkierteelle M20 x 1,5 vaaleanharmaa

Industrial cable entry often requires adapting a pre-existing KEB Quick-In opening to a standard metric thread. This adapter solves that mismatch by providing a secure transition from the KEB Quick-In system to an M20 x 1.5 male thread, enabling the connection of standard metric conduit or cable glands without modifying the enclosure.

Who is it for

Maintenance technicians, panel builders, and machine OEMs who work with enclosures or machines fitted with KEB Quick-In cable entry ports and need to attach metric-threaded cable glands or conduits.

Main features

• Direct interface: KEB Quick-In female to M20 x 1.5 male thread.
• Made from light grey polyamide (PA), halogen-free and UV-resistant.
• Includes EPDM gasket for reliable sealing.
• Wrench size 24 mm for easy installation.

Specifications

• Adapter type: Thread adapter
• System compatibility: KEB Quick-In
• Connection 1 (system side): KEB Quick-In female
• Connection 2 (thread side): M20 x 1.5 male
• Thread pitch: 1.5 mm
• Material: Polyamide (PA)
• Colour: Light grey (RAL 7035)
• Operating temperature range: -40°C to +100°C
• Mounting type: Screw-in
• Wrench size: 24 mm
• Gasket material: EPDM

Tips

Ensure the mating surfaces are clean and the gasket is properly seated before tightening to the recommended torque. For outdoor applications, the UV-resistant polyamide and EPDM gasket provide long-term durability.
