S CONN MAXIMUM CONNECTIVITY Cat.6A suojattu työkaluton Keystone Jack, RJ45, 10G, 500 MHz, hopea 75726-AW

Cat.6A shielded keystone jack with tool-free IDC termination, delivering 10 Gigabit Ethernet performance up to 500 MHz. The die-cast zinc housing with nickel plating ensures robust shielding and durability, while gold-plated contacts (50µ") guarantee reliable signal integrity for demanding network installations.

Advantages

Tool-free termination speeds up installation without sacrificing connection quality. The shielded design protects against electromagnetic interference, and the keystone snap-in mounting fits standard wall plates and patch panels. Supports Power over Ethernet up to PoE++ (IEEE 802.3bt) for powering devices through the same cable.

Suitable for

• 10GBASE-T network infrastructures in offices and data centres
• High-density patching environments requiring reliable shielded connections
• PoE applications such as IP cameras, wireless access points, and VoIP phones

Key specifications

• Category: Cat.6A (Class EA)
• Shielding: Shielded (STP/FTP)
• Connector: RJ45 (8P8C), front
• Termination: Tool-free IDC, AWG 22-24 solid or stranded
• Wiring: TIA/EIA 568A/B
• Bandwidth: 500 MHz
• Mating cycles: ≥ 750
• Operating temperature: -10°C to +60°C

Recommendations

For best performance, pair with Cat.6A shielded patch cables and ensure proper grounding of the shielded system. Use in conjunction with shielded patch panels and wall plates to maintain end-to-end shielding integrity.
