SC-liitin Corning UniCam 95-050-40 monimuotokuitu keraamisella ferruulilla

SC connector Corning UniCam 95-050-40 is a multimode fibre optic network connector designed for termination of 50/125 µm multimode optical fibre. The connector uses a ceramic ferrule to ensure precise mechanical alignment and stable optical performance, and is suitable for use in datacentre, enterprise LAN and patch panel installations that require reliable multimode connections.

Advantages

The Corning UniCam SC multimode connector provides consistent insertion loss and repeatable mating performance thanks to its ceramic ferrule and factory-controlled geometry. It is designed for easy fibre termination and integration into standard SC ports, offering compatibility with multimode 50/125 µm systems and robust mechanical alignment for stable long-term operation.

Suitable for

• Datacentre multimode fibre patching and panels
• Enterprise LAN backbone and horizontal cabling
• Field termination where low-loss SC multimode connections are required

Key specifications

• Brand: Corning
• Model / MPN: 95-050-40 (UniCam)
• Connector type: SC multimode, male
• Fibre type: Multimode
• Core / cladding diameter: 50/125 µm
• Ferrule material: Ceramic
• EAN: 4042673619499

How to use

Prepare the 50/125 µm multimode fibre according to standard termination procedures (strip, cleave and clean). Use the Corning UniCam termination process or compatible termination tools to secure the fibre into the SC connector body, verify ferrule endface cleanliness and perform insertion loss and return loss tests after termination. Insert the completed connector into standard SC multimode ports or adaptors for network use.

Recommendations

Handle ferrule endfaces with care: always inspect and clean before mating, follow manufacturer termination guidelines for best optical performance, and validate each connection with appropriate test equipment.
