Supermicro 1U Ultra Riser PCIE/M.2 hybridi RSC-UMR-8

The Supermicro RSC-UMR-8 is a 1U Ultra Riser Card designed to add both PCIe 3.0 x16 expansion and M.2 NVMe storage capability to Supermicro Ultra Series servers. This hybrid riser card supports a single PCIe 3.0 x16 slot and one M.2 slot (M-key) with PCIe 3.0 x4 interface, compatible with M.2 form factors 2242, 2260, 2280, and 22110. It connects via an edge connector to the motherboard and features a right-angle orientation for optimal space utilization in 1U chassis.

Advantages

Maximizes server expansion capabilities by combining PCIe and M.2 support in a single riser card. The hybrid design allows for flexible configuration, enabling both high-speed storage and additional PCIe devices. Engineered for Supermicro Ultra Series servers, ensuring seamless integration and reliable performance.

Suitable for

• Supermicro Ultra Series 1U servers requiring additional PCIe and M.2 NVMe storage
• Data centers and enterprise environments needing compact server expansion
• Upgrading server storage with NVMe SSDs while retaining PCIe expansion slots

Key specifications

• Product Type: Riser Card
• Form Factor: 1U Ultra
• PCI Express Generation: PCIe Gen3
• PCI Express Slot Configuration: 1 x PCIe 3.0 x16
• M.2 Slot Configuration: 1 x M.2 (M-key)
• M.2 Interface: PCIe 3.0 x4
• M.2 Form Factor Support: 2242, 2260, 2280, 22110
• Compatibility: Supermicro Ultra Series Servers
• Connector Type: Edge Connector (for motherboard)
• Orientation: Right-angle
• Hybrid Support: Yes (PCIe and M.2)
• Application: Server Expansion
• Bus Type: PCI Express
• Manufacturer Part Number: RSC-RR1U-E16R

Recommendations

For optimal performance, pair this riser card with Supermicro Ultra Series motherboards and compatible NVMe M.2 SSDs. Ensure your server BIOS is updated to support PCIe bifurcation if using both slots simultaneously.
