Supermicro SuperServer 5019D-4C-FN8TP 1U räkkipalvelin Intel Xeon D-2123IT 4-ydin 2.2 GHz

Compact 1U rackmount server engineered for edge computing, network security, and virtualization, delivering high-performance processing with Intel Xeon D-2123IT (4C/8T, 2.2 GHz) in a short-depth chassis.

Advantages

Short-depth design fits shallow racks and wall-mount enclosures. Dual 10G SFP+ and dual 10GBASE-T ports provide flexible high-speed networking. IPMI 2.0 with dedicated LAN enables remote management and KVM over IP. Low-noise 200W AC-DC power supply ensures quiet operation.

Suitable for

• Edge computing and IoT gateways
• Network security appliances (firewall, VPN, SD-WAN)
• Virtualization and hyper-converged infrastructure
• Small to medium business server rooms

Key specifications

• Form Factor: 1U Rackmount, Short-depth
• Processor: Intel Xeon D-2123IT (4C/8T, 2.2 GHz, 85W)
• Memory: 4x DDR4 DIMM slots, up to 256GB RDIMM / 128GB UDIMM
• Storage: 4x 3.5" Hot-swap SATA3 bays (supports 2.5" with optional trays)
• M.2: 1x M.2 NVMe/SATA (M-key, 2242/2280/22110)
• Networking: Dual 10G SFP+, Dual 10GBASE-T, Dual 1GbE LAN
• Expansion: 1x PCI-E 3.0 x8 (Low-profile)
• USB: 2x USB 3.0 (rear), 2x USB 2.0 (front)
• Video: 1x VGA port
• Power: 200W Low Noise AC-DC with PFC
• Management: IPMI 2.0 with KVM over IP, Dedicated LAN
• Operating Temperature: 0°C to 50°C

Recommendations

Ideal for customers requiring a compact, reliable server for edge deployments, network functions, and space-constrained environments, offering robust networking and remote management.
