TDK Grenton 24VDC 2.5A DIN-kiskovirtalähdemoduuli PSU-242-5-02

The TDK Grenton PSU-242-5-02 is a high-efficiency DIN rail power supply module delivering a stable 24V DC output at 2.5A (60W). Designed for industrial and building automation applications, it ensures reliable power conversion from a wide AC input range with comprehensive protection features.

Advantages

Compact DIN rail mounting saves cabinet space. Natural convection cooling ensures silent operation and long life. High efficiency (>85%) reduces energy loss and heat generation. Built-in protections safeguard connected equipment against short circuits, overloads, overvoltage, and overtemperature.

Suitable for

• Industrial control panels
• Building automation systems
• PLC and sensor power supply
• Security and access control systems

Key specifications

• Input: 100-240V AC, 50/60 Hz
• Output: 24V DC, 2.5A, 60W
• Mounting: DIN Rail
• Efficiency: >85%
• Protection: Short Circuit, Overload, Overvoltage, Overtemperature
• Operating Temperature: -20°C to +50°C
• Cooling: Natural Convection
• Connectors: Screw Terminals
• LED Indicator: Green Power ON
• Housing: Plastic
• Certifications: CE, RoHS

Recommendations

For optimal performance, ensure adequate ventilation around the module. Use appropriate wire gauge for screw terminals. This power supply is ideal for powering 24V devices in distributed automation networks.
