Tehovastus ALLNET Brick’R’knowledge 10W 1Ω malli ALL-BRICK-0662

The ALLNET Brick’R’knowledge 10W 1Ω power resistor ALL-BRICK-0662 is a fixed through-hole resistor designed to dissipate up to 10 watts while providing a precise 1 ohm resistance. It is intended for use in electronic circuits where compact, reliable power dissipation or current limiting is required. The component is suitable for prototyping, repairs and small-scale applications where a robust 10 W, low-value resistor is needed; verify mounting and through-hole dimensions against your PCB or chassis before installation.

Advantages

This power resistor offers stable performance at its rated power and resistance value, with construction appropriate for repeated use in test and prototype environments. Its compact form factor simplifies placement in tight circuit layouts and makes it convenient for retrofit repairs. As a fixed resistor, it requires no adjustment and provides a predictable load or current-limiting element in DC and non-critical AC circuits.

Suitable for

• Load testing of power supplies and battery packs
• Current limiting in simple power circuits and prototypes
• Replacement or repair of equipment requiring a 10 W, 1 Ω through-hole resistor
• Bench prototyping and experimental circuits where a discrete power resistor is needed

Key specifications

• Power rating: 10 W continuous dissipation (subject to proper cooling and mounting)
• Resistance value: 1 Ω fixed
• Tolerance: typical for fixed power resistors (refer to manufacturer datasheet for exact tolerance)
• Mounting type: through-hole / PCB assembly (verify mechanical dimensions before use)
• Typical operating environment: application-dependent; ensure adequate ventilation and heat sinking for sustained loads

How to use

Install the resistor into a PCB or chassis using its through-hole leads, ensuring correct mechanical clearance and secure solder joints. Allow for adequate airflow and, where necessary, attach to a heatsink or use thermal pads to maintain safe operating temperature when dissipating close to the rated 10 W. Check circuit design and verify that a fixed 1 Ω value and the resistor's power rating are appropriate for the intended current and voltage to avoid overheating or damage. For initial testing, start with lower duty cycles or reduced voltage to confirm thermal behavior.

Recommendations

Use the resistor with appropriate thermal management in sustained high-power applications. Avoid operating continuously at full rated power without adequate cooling. Confirm physical lead spacing and board layout compatibility before soldering to prevent mechanical stress or insufficient heat dissipation.
