Uni-T UT161E True RMS digitaalimittari 60000 Counts

The Uni-T UT161E is a high-performance True RMS digital multimeter designed for professional electricians and engineers. With a 60000-count display and advanced measurement capabilities, it delivers exceptional accuracy and reliability for demanding applications.

Advantages

Featuring True RMS measurement for both AC voltage and current, the UT161E ensures accurate readings even with non-sinusoidal waveforms. The built-in Low-Pass Filter (LPF) stabilizes measurements on variable frequency drives, while LoZ (Low Impedance) mode eliminates ghost voltages. The large backlit display with bar graph enhances readability in low-light conditions.

Suitable for

• Industrial electrical maintenance
• HVAC system troubleshooting
• Automotive diagnostics
• Laboratory and field service

Key specifications

• Display Count: 60000
• True RMS: ACV and ACA
• Max DC Voltage: 1000V
• Max AC Voltage: 1000V
• Max DC Current: 10A (20A for 10s)
• Max AC Current: 10A (20A for 10s)
• Max Resistance: 60MΩ
• Max Capacitance: 60mF
• Frequency Measurement: Up to 60MHz
• Temperature Measurement: -40°C to 1000°C
• NCV (Non-Contact Voltage): Yes
• Low Pass Filter (LPF): Yes
• LoZ (Low Impedance): Yes
• Safety Rating: CAT III 1000V, CAT IV 600V
• Power Source: 9V Battery (6F22)
• Auto Ranging: Yes
• Diode Test: Yes
• Continuity Test: Yes (with buzzer)
• Data Hold: Yes
• Backlight: Yes

Recommendations

For professionals requiring high precision and advanced features, the Uni-T UT161E is an excellent choice. Its robust safety ratings and versatile measurement functions make it suitable for a wide range of electrical testing tasks.
