Victron Energy SmartSolar MPPT 250/100-Tr VE.Can aurinkolataussäädin

The SmartSolar MPPT 250/100-Tr VE.Can stands apart from typical solar charge controllers by combining an ultra-fast Maximum Power Point Tracking algorithm with integrated Bluetooth Smart for wireless programming and monitoring. It auto-selects 12, 24, 36, or 48 V battery systems and delivers up to 100 A of charging current, making it a versatile powerhouse for large off-grid and grid-tie solar installations.

Highlights

• Ultra-fast MPPT tracking for maximum energy harvest, even under rapidly changing light conditions
• Built-in Bluetooth Smart: configure, monitor, and update firmware via the VictronConnect app
• Wide PV input voltage up to 250 V open circuit, enabling long series strings and reduced wiring costs
• Multi-stage adaptive charge algorithm with temperature compensation for optimal battery life
• VE.Can communication port for seamless integration with GX devices, Color Control, and other VE.Can products
• Programmable relay and remote on/off port for advanced system control
• Robust design with IP43 protection for electronics and IP22 for connection area

In daily use

Installation is straightforward thanks to the MC4 PV connectors and clear terminal layout. The controller's internal temperature sensor automatically adjusts charging voltage based on battery temperature, preventing overcharge in hot conditions and undercharge in cold. The VictronConnect app provides real-time data and historical trends, allowing you to fine-tune settings or update firmware from your smartphone. The programmable relay can be used for generator start, alarm, or load control, adding a layer of automation to your energy system.

Full specifications

• Battery voltage: 12/24/36/48 V Auto Select
• Maximum battery charge current: 100 A
• Maximum PV open circuit voltage: 250 V
• Nominal PV power: 1450 W (12 V), 2900 W (24 V), 5800 W (48 V)
• MPPT efficiency: 98%
• Self-consumption: less than 30 mA
• Charge algorithm: multi-stage adaptive (Bulk, Absorption, Float, Equalize)
• Communication interfaces: VE.Direct, Bluetooth Smart, VE.Can
• PV connector type: MC4
• Enclosure protection: IP43 (electronic components), IP22 (connection area)
• Operating temperature range: -30 to +60 °C (full power up to 40 °C)
• Remote on/off port: Yes
• Programmable relay: Yes
• PV input current limit: 70 A
• Internal temperature sensor: Yes

Final note

The SmartSolar MPPT 250/100-Tr VE.Can is a professional-grade charge controller that combines high power handling with smart connectivity, ensuring your solar system operates at peak efficiency for years to come.
