VIDICON CROW SWAN 1000 GSM/GPRS -viestintämoduuli

The VIDICON CROW SWAN 1000 is a GSM/GPRS communicator module that delivers dependable alarm event transmission over quad-band cellular networks. Its strongest capability is dual-path reporting via GPRS and SMS, ensuring critical signals reach monitoring stations even when landlines fail.

Advantages

This module integrates seamlessly with virtually any alarm control panel, thanks to its four programmable inputs and two open-collector outputs. It supports both NO/NC and EOL configurations, making retrofits straightforward. Remote programming via GPRS and firmware upgrades over the air eliminate the need for on-site visits, while the built-in event log aids in diagnostics. Voice call reporting adds an extra layer of redundancy for high-security installations.

Suitable for

• Residential and commercial intrusion alarm systems requiring cellular backup
• Upgrading existing wired panels to wireless monitoring
• Installations in areas without reliable PSTN lines
• Security integrators seeking a universal communicator for mixed panel fleets

Key specifications

• Quad-band GSM 850/900/1800/1900 MHz with GPRS/EDGE
• 4 programmable inputs (NO/NC/EOL) and 2 open-collector outputs (100 mA)
• Reporting protocols: SIA and Contact ID via GPRS or SMS
• Power supply: 10–28 V DC, max current 200 mA
• Standard SIM (2FF) and SMA antenna connector
• Operating temperature: -10 °C to +55 °C
• Plastic enclosure for indoor mounting

Recommendations

For reliable alarm communication, pair the SWAN 1000 with a high-gain SMA antenna and a dedicated SIM card for uninterrupted monitoring.
