VOLTAGE pöytävirtalähde 12V 3A 36W CCTV-käyttöön, 5,5mm/2,1mm holkkipistoke

The VOLTAGE VED12030 is a high-performance desktop AC/DC power adapter designed specifically for CCTV systems and other devices requiring a stable 12V DC power source. With an output of 12V/3A (36W) and a standard 5.5mm/2.1mm barrel plug, this power supply ensures reliable operation for security cameras, DVRs, and compatible electronics. It features a compact desktop form factor with an IEC C8 (Figure-8) input connector, making it easy to integrate into any setup. The adapter meets DOE Level VI efficiency standards and includes comprehensive protection features for safe and durable use.

Advantages

This power supply offers several key benefits: high efficiency reduces energy waste and heat generation; multiple protection circuits (OVP, OCP, SCP) safeguard connected equipment; compact design saves space; and the 1.2-meter DC output cable provides flexible placement. It is a cost-effective and reliable solution for powering 12V devices up to 3A.

Suitable for

• CCTV cameras and surveillance systems
• Digital video recorders (DVRs) and network video recorders (NVRs)
• LED strip lights and low-voltage lighting
• Routers, switches, and networking equipment
• Any device requiring 12V DC and drawing 3A or less

Key specifications

• Product Type: AC/DC Power Adapter (Desktop)
• Input: 100-240V AC, 50/60 Hz
• Output: 12V DC, 3A, 36W
• DC Connector: 5.5mm outer diameter / 2.1mm inner diameter, center positive
• AC Input Connector: IEC C8 (Figure-8)
• DC Cable Length: Approx. 1.2 meters
• Efficiency: DOE Level VI
• Protection: Over Voltage, Over Current, Short Circuit
• Operating Temperature: 0°C to 40°C
• Certifications: CE, RoHS

Recommendations

For optimal performance, use only with devices that require 12V DC and do not exceed 3A current draw. Ensure the DC plug polarity matches your device (center positive). The AC power cord is not included; use a standard IEC C8 cord. This adapter is not suitable for outdoor use unless placed in a weatherproof enclosure.
