Wireless shield ALLNET ALL-B-66

The ALLNET ALL-B-66 wireless shield is a compact accessory designed for 4Duino compatibility, enabling wireless communication for development projects. It features a black and green design and weighs approximately 40 g, providing a lightweight add-on for prototyping and embedded applications.

Advantages

The shield provides a simple way to add wireless connectivity to a 4Duino board without altering the main development board. Its small size and low weight make it suitable for portable projects. The USB-TTL interface simplifies connection to host devices and serial communication for configuration and data exchange.

Suitable for

• Prototyping wireless IoT devices with 4Duino
• Embedded projects requiring serial wireless communication
• Portable or battery-powered development prototypes

Key specifications

• Brand: ALLNET
• Model: ALL-B-66
• Compatibility: 4Duino
• Interface: USB-TTL
• Weight: ~40 g
• EAN: 4038816027337

How to use

Mount the ALLNET ALL-B-66 shield onto a compatible 4Duino development board following the board's connector orientation. Use the USB-TTL interface to connect to a host PC or serial adapter for configuration, firmware updates, or data exchange. Configure wireless settings via the development environment or serial commands supported by your 4Duino setup.

Recommendations

Use the shield in environments with minimal radio interference for reliable communication. Verify connector orientation before powering the board, and consult 4Duino documentation for correct pin mapping and serial settings.
