Wirewin WKS CON MOD johdinliitin harmaa

Telecom installers and network technicians rely on the Wirewin WKS CON MOD for quick, reliable wire joining in distribution boxes and LSA strips. This grey LSA connection module provides a single IDC connection point for solid or stranded copper wires from 0.4 to 0.8 mm (AWG 26-20).

Key specifications

• Product type: LSA connection module
• Connector type: IDC (insulation displacement)
• Connection technology: LSA-Plus compatible
• Number of wires connected: 2
• Colour: Grey
• Housing material: Plastic
• Contact material: Phosphor bronze, tin-plated
• Compatible wire gauge: 0.4 - 0.8 mm (AWG 26 - AWG 20)
• Wire type: Solid and stranded copper wires
• Mounting: For LSA strips / distribution boxes
• Dielectric strength: > 2 kV (RMS, 50 Hz, 1 min)
• Insulation resistance: > 100 MΩ (at 100 V DC)
• Operating temperature: -20°C to +70°C
• Standards compliance: RoHS
• Installation: Tool-less or with LSA insertion tool

Why choose it

Its LSA-Plus compatible design ensures secure, gas-tight connections without stripping, saving time on every splice. The tin-plated phosphor bronze contacts resist corrosion, maintaining signal integrity in demanding telecom environments.

Ideal use cases

• Telephone line repair and extension
• Data network cable splicing
• Distribution box terminations
• Maintenance of existing LSA installations

Good to know

The module is RoHS compliant and operates reliably from -20°C to +70°C. It accepts both solid and stranded copper wires, offering flexibility for various cabling standards.
