Wolfcraft porausohjain piilosaranoille 4642100

For cabinet makers and furniture assemblers who mount concealed hinges on doors, the Wolfcraft drill guide 4642100 ensures the 35 mm hinge cup and 2.5 mm mounting screw holes are drilled quickly, precisely, and at the correct edge distance every time.

Key specifications

• Product type: Drill Guide / Jig
• Application: Installation of concealed hinges
• Hinge cup drill diameter: 35 mm
• Mounting screw drill diameter: 2.5 mm
• Edge distance adjustment range: 3 - 7 mm
• Material: High-quality plastic (ABS)
• Suitable for material thickness: 15 - 25 mm
• Integrated depth stop: Yes, for 35mm drill bit
• Positioning aid: Integrated scale and adjustable stop
• Compatibility: Standard concealed hinges
• Recommended drill type: Cordless drill or electric drill
• Colour: Grey/Blue

Why choose it

The integrated depth stop prevents drilling too deep, while the adjustable edge distance stop and scale allow repeatable positioning from 3 to 7 mm. It works with standard concealed hinges and fits material thicknesses from 15 to 25 mm, making it a reliable jig for consistent results.

Ideal use cases

• Drilling hinge cup holes in cabinet doors
• Aligning mounting screw holes for concealed hinges
• Batch production of furniture fronts
• On-site installation and repair work

Good to know

The guide is made from high-quality ABS plastic for durability and easy handling. It is designed for use with a cordless or electric drill and includes one drill guide. No additional components are required for standard concealed hinge installation.
