APC A9F03132 johdonsuojakatkaisija 32A 3P C-käyrä 10kA

The APC A9F03132 is a high-performance miniature circuit breaker (MCB) designed for reliable overcurrent and short-circuit protection in electrical installations. With a rated current of 32 A, 3 poles, and a C tripping curve, this MCB is ideal for protecting circuits with moderate inrush currents, such as lighting and motor loads. It offers a breaking capacity of 10 kA at 400 V AC, ensuring robust protection in industrial and commercial environments.

Advantages

This MCB provides reliable protection against overloads and short circuits, with a compact design for easy DIN rail mounting. The C-curve characteristic ensures compatibility with a wide range of loads, while the high breaking capacity guarantees safety under fault conditions. The tunnel-type terminals simplify wiring, and the IP20 front face protection allows safe installation in distribution boards.

Suitable for

• Industrial and commercial electrical panels
• Protection of lighting circuits, motors, and transformers
• Residential distribution boards requiring high breaking capacity
• Applications requiring 3-pole protection up to 32 A

Key specifications

• Product Type: Miniature Circuit Breaker (MCB)
• Number of Poles: 3P
• Rated Current (In): 32 A
• Tripping Curve: C
• Breaking Capacity (Icn): 10 kA at 400 V AC (IEC 60898-1)
• Rated Operational Voltage (Ue): 400 V AC 50/60 Hz
• Rated Insulation Voltage (Ui): 500 V AC
• Rated Impulse Withstand Voltage (Uimp): 6 kV
• Degree of Protection: IP20 (front face), IP40 (in enclosure)
• Mounting Type: DIN Rail
• Terminal Type: Tunnel type terminals
• Cable Capacity (Flexible): 1 to 25 mm²
• Cable Capacity (Rigid): 1 to 35 mm²
• Mechanical Endurance: 20000 cycles
• Electrical Endurance: 10000 cycles
• Operating Temperature: -35 to 70 °C
• Storage Temperature: -40 to 85 °C
• Standards: IEC 60898-1, IEC 60947-2

Recommendations

For optimal performance, ensure proper sizing according to the load and cable cross-section. This MCB is suitable for use in distribution boards with IP40 enclosures. Always follow local electrical codes and manufacturer guidelines during installation.
