Black Box 4K HDMI Switch 2x1 - videoswitch

The Black Box 4K HDMI Switch 2x1 allows you to connect two HDMI sources to a single 4K display, supporting resolutions up to 3840x2160 at 60Hz. Ideal for home theaters, conference rooms, and digital signage, this switch delivers pristine video and audio quality with HDMI 2.0 compliance and HDCP 2.2 support.

Advantages

Seamlessly switch between two HDMI inputs using front panel buttons, IR remote, RS-232, or USB control. Enjoy 18 Gbps data rate, deep color (8/10/12-bit), and chroma subsampling 4:4:4 for lifelike images. Supports advanced audio formats including Dolby TrueHD and DTS-HD Master Audio. Metal housing ensures durability and ESD protection.

Suitable for

• Home entertainment systems with multiple sources
• Professional AV installations requiring reliable switching
• Digital signage and presentation setups

Key specifications

• Inputs: 2x HDMI (Type A female)
• Output: 1x HDMI (Type A female)
• Max Resolution: 4K@60Hz (3840x2160)
• HDMI Standard: HDMI 2.0
• HDCP: 2.2 / 1.4
• Data Rate: 18 Gbps
• Color Depth: 8/10/12-bit
• Chroma Subsampling: 4:4:4, 4:2:2, 4:2:0
• Audio: LPCM 2.0/5.1/7.1, Dolby Digital, DTS, Dolby TrueHD, DTS-HD Master Audio
• Control: Front panel buttons, IR remote, RS-232, USB
• Power: DC 5V/1A
• Housing: Metal
• Operating Temperature: 0 to 40°C

Recommendations

For optimal performance, use high-quality HDMI cables and ensure your display supports 4K@60Hz. The switch is compatible with most HDMI sources and displays.
