CABLES2GO C2G 1m LC/LC OM4 LSZH kuitu-patch-kaapeli - violetti

The CABLES2GO C2G 1m LC/LC OM4 LSZH Fibre Patch Cable in purple is a high-performance fibre optic patch cable designed for reliable, high-speed data transmission in data centers, enterprise networks, and telecommunications environments. With OM4 multimode fiber, it supports data rates up to 100 Gbps over short distances, making it ideal for 40/100 Gigabit Ethernet applications. The cable features LC duplex connectors on both ends, a durable LSZH (Low Smoke Zero Halogen) jacket for safety in confined spaces, and a vibrant purple color for easy identification.

Advantages

This fibre patch cable offers exceptional bandwidth and low insertion loss, ensuring minimal signal degradation. The LSZH jacket reduces toxic and corrosive gas emissions in case of fire, making it suitable for use in air-handling spaces. The duplex design allows for bidirectional communication, and the UPC polish provides excellent return loss performance.

Suitable for

• Data center interconnects
• High-speed network switches and routers
• Storage area networks (SAN)
• Telecommunications equipment
• Any application requiring reliable OM4 multimode fiber connectivity

Key specifications

• Cable Type: Fibre Optic Patch Cable
• Fiber Type: OM4 Multimode
• Connector A: LC Multi-Mode (Male)
• Connector B: LC Multi-Mode (Male)
• Cable Length: 1 m
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Fiber Core Diameter: 50 µm
• Fiber Cladding Diameter: 125 µm
• Number of Fibers: 2 (Duplex)
• Cable Color: Purple
• Connector Polish: UPC
• Maximum Data Rate Support: 100 Gbps
• Insertion Loss (Typical): ≤ 0.3 dB
• Return Loss (Typical): ≥ 30 dB
• Operating Wavelengths: 850 nm, 1300 nm
• Modal Bandwidth (850nm): 4700 MHz-km
• Modal Bandwidth (1300nm): 500 MHz-km
• Standards Compliance: TIA/EIA-568-C.3, ISO/IEC 11801, RoHS

Recommendations

For optimal performance, ensure that the connectors are clean before installation. This cable is compatible with all standard LC duplex ports. It is recommended for use in high-density patching environments where space and safety are critical.
