Dahua BP5E-4GP 5MP WLAN-6-akku-IP-kamera

The Dahua BP5E-4GP is a 5 MP IP security camera with Wi-Fi 6 connectivity and a built-in battery that can be charged via solar panel. It delivers detailed images even in low light and features smart detection for people and vehicles, plus active deterrence with light and sound.

Key features

• 5 MP resolution (2880 × 1620) for clear, detailed images
• Wi-Fi 6 (2.4 GHz and 5 GHz) with Bluetooth pairing
• Dual Light illumination: IR up to 30 m and warm light up to 20 m
• AI-based human and vehicle detection
• Active deterrence with sound and flashing light
• Two-way audio with built-in microphone and speaker
• Local storage via microSD card up to 512 GB
• Built-in rechargeable battery and solar panel charging support
• USB Type-C power
• IP66 weather resistance

Specifications

• Brand: Dahua
• Model: BP5E-4GP
• Product type: IP Security Camera
• Maximum resolution: 5 MP (2880 × 1620)
• Image sensor: 1/3" CMOS
• Lens: fixed focal length 3.6 mm, aperture F1.6
• Field of view: horizontal 78.4°, vertical 42.4°, diagonal 92.4°
• IR range: up to 30 m
• Warm light range: up to 20 m
• Illuminators: 2 × IR LED + 2 × warm light
• Pan range: 0°–350°; Tilt range: 0°–90°
• Video compression: H.265
• Frame rate: main stream 2880 × 1620 at 1–15 fps
• Video bit rate: H.265: 32 kb/s–4096 kb/s
• WDR: Yes
• Motion detection: on/off; up to 4 rectangular detection areas
• Built-in microphone: Yes
• Built-in speaker: Yes
• Audio compression: G.711a / G.711Mu / PCM
• Network port: RJ-45 (10/100 Base-T)
• Wi-Fi: Yes
• Wi-Fi standards: Wi-Fi 6
• Cellular connectivity: 4G LTE
• 4G bands – Europe (-EAU/EUR): FDD-LTE: B1/B3/B5/B7/B8/B20/B28; TDD-LTE: B38/B40/B41
• 4G transmit power: Power Class 3: 23 dBm ±2.7 dB
• Supported region – EAU/EUR version: Europe
• 4G bands – Latin America (-LA): FDD-LTE: B2/B3/B4/B5/B7/B8/B28/B66; TDD-LTE: B38/B40/B41
• Supported region – LA version: Latin America
• Storage: Micro SD card up to 512 GB
• Software: DMSS
• Mobile app: iOS / Android
• Certifications: CE-LVD: EN 62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; CE-RED: Radio Equipment Directive 2014/53/EU
• Power supply: USB, 5 V DC ±5%, 2 A
• Power consumption – performance mode: 1.22 W
• Power consumption – AOV mode: 0.1 W
• Power consumption – Ultra Power Saving mode: 0.02 W
• Operating temperature: -20°C to +50°C
• Operating humidity: ≤95% RH, non-condensing
• International Protection (IP) code: IP66
• Buttons: Reset; power
• Housing material: Plastic
• Dimensions: 162.4 × 141.2 × 248.8 mm (L × W × H)
• Net weight: 0.73 kg
• Battery capacity: 36 Wh
• Charging temperature: 0°C to +50°C
• Discharging temperature: -20°C to +60°C
• Solar panel maximum power: 8 W
• Solar panel cell type: Monocrystalline silicon
