Eaton Z-SLS/B-25A 3-napainen pääsuojakytkin 25A 400V AC/220V DC 268990

Main circuit breaker with thermomagnetic trip and B characteristic, rated 25 A, 3-pole, for 400 V AC or 220 V DC systems. High breaking capacity of 25 kA ensures reliable protection in industrial and commercial installations.

Advantages

DIN rail mounting and screw terminals with wide capacity (1.5–50 mm² rigid, 1.5–35 mm² flexible) simplify installation. The disconnector function allows safe isolation for maintenance. Complies with EN 60947-2 and VDE 0660 Part 101.

Suitable for

• Main distribution boards
• Industrial control panels
• DC applications up to 220 V

Key specifications

• Rated current: 25 A
• Number of poles: 3
• Rated voltage: 400 V AC / 220 V DC
• Breaking capacity: 25 kA
• Characteristic curve: B
• Mounting: DIN rail (EN 60715)
• Module width: 3 TE
• Operating temperature: -25 to +50 °C

Recommendations

Verify short-circuit current at installation point does not exceed 25 kA. Use appropriate torque for screw terminals.
