EFB Elektronik Simplex-patchkaapeli SC/APC Singlemode OS2 G.657.A2 1m keltainen LSZH

The EFB Elektronik Simplex Patch Cable is a high-performance fiber optic patch cable designed for reliable single-mode connections. Featuring SC/APC connectors on both ends, this cable ensures low insertion loss and high return loss, making it ideal for FTTH, CATV, and telecommunication networks. The OS2 fiber class with G.657.A2 bend-insensitive technology allows for tight bends without signal degradation. With a 1-meter length and yellow LSZH jacket, it is perfect for indoor installations where safety and space are critical.

Advantages

This patch cable offers exceptional signal integrity with typical insertion loss ≤0.3 dB and return loss ≥60 dB. The LSZH jacket reduces toxic fumes in case of fire, ensuring safety in enclosed spaces. The G.657.A2 fiber supports a minimum bend radius of only 10 mm, enabling flexible routing in patch panels and cabinets. Simplex design provides a single fiber connection for point-to-point links.

Suitable for

• FTTH (Fiber to the Home) installations
• CATV networks
• Telecommunication and data center patching
• Indoor fiber optic connections requiring low smoke zero halogen materials

Key specifications

• Connector Type: SC/APC (both ends)
• Fiber Mode: Single-mode OS2
• Fiber Core/Cladding: 9/125 µm
• Fiber Standard: G.657.A2
• Cable Length: 1 m
• Jacket Color: Yellow
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Insertion Loss: ≤0.3 dB typical
• Return Loss: ≥60 dB typical
• Operating Temperature: -20°C to 70°C
• Minimum Bend Radius: 10 mm
• Attenuation: ≤0.35 dB/km @ 1310nm, ≤0.25 dB/km @ 1550nm
• Ferrule Material: Zirconia Ceramic
• Compliance: RoHS, REACH

Recommendations

For optimal performance, ensure connectors are clean before mating. This cable is compatible with standard SC/APC adapters and is suitable for use in both horizontal and vertical cabling systems. Store in a clean, dry environment within the specified temperature range.
