Finder asennuskontaktori 24V AC/DC, 1NO+1NC, LED 22.32.0.024.4540

The Finder 22.32 series installation contactor combines a compact 17.5 mm DIN rail housing with a 25 A switching capability, making it a space-efficient choice for lighting and heating control in residential and commercial panels. Unlike typical modular contactors that require separate coil voltage variants, this model accepts both 24 V AC and 24 V DC coil supply, simplifying stock and installation.

Highlights

• Coil voltage: 24 V AC/DC
• Contact configuration: 1 normally open (NO) + 1 normally closed (NC)
• Rated current: 25 A (AC-1)
• Green LED coil indicator
• DIN rail mounting, width 17.5 mm

In daily use

The green LED provides immediate visual confirmation of coil energisation, aiding troubleshooting in crowded distribution boards. The mixed contact set (1 NO + 1 NC) allows the contactor to serve as a changeover device for two independent circuits, such as switching between day and night loads or controlling a signal lamp alongside a power circuit.

Full specifications

• Rated voltage: 250 V AC (AC-1)
• Number of poles: 2
• Electrical life (AC-1): 100,000 operations
• Mechanical life: 1,000,000 operations
• Operating temperature range: -40 to +40 °C
• AC coil power consumption: 2.5 VA
• DC coil power consumption: 1.5 W
• Maximum switching power (AC-1): 6.25 kVA
• Dielectric strength (coil/contacts): 4 kV AC
• Protection degree: IP20

Final note

A reliable and compact solution for 24 V control circuits, the Finder 22.32.0.024.4540 offers clear status indication and versatile contact arrangement in a single-module footprint.
