Gira pinta-asennusrasia 3-kertainen antrasiitti 5504910

Surface mount box for Gira System 55 inserts, providing a flat, robust enclosure for indoor installations. The 3-gang anthracite housing offers a clean finish and pre-punched cable entries for straightforward wiring.

Advantages

Made from halogen-free, UV-resistant thermoplastic, this box is built for durability in dry indoor environments. Its impact resistance (IK05) ensures resilience against mechanical stress, while the anthracite colour (RAL 7021) blends seamlessly with modern interiors.

Suitable for

• Gira System 55, E2, Event, Esprit, Standard 55, and F100 series inserts
• Surface mounting on solid walls in residential or commercial dry rooms
• Applications requiring a 3-gang enclosure with a flat design

Key specifications

• Product type: Surface mount box
• Mounting type: Surface mounting
• Number of gangs: 3
• Colour: Anthracite (RAL 7021)
• Material: Thermoplastic (PC)
• Brand compatibility: Gira
• Series compatibility: System 55, E2, Event, Esprit, Standard 55, F100
• Ingress protection: IP20
• Halogen-free: Yes
• UV-resistant: Yes
• Impact resistance: IK05
• Application area: Indoor, dry rooms
• Design: Flat
• Operating temperature: -5 to +45 °C
• Cable entry: Pre-punched
• With cover: Yes
• Width: 426 mm
• Depth: 25.4 mm
• Height: 106.5 mm

Recommendations

For a cohesive installation, pair this surface mount box with Gira System 55 inserts in anthracite. Ensure the mounting surface is flat and dry, and use appropriate fixings for the wall material.
