GÜDE 8025-1 Expert Power Control NET 4x C13, porttikohtainen mittaus, 2x anturiportti

The GüDE 8025-1 Expert Power Control NET is a professional-grade switched and metered PDU designed for remote power management of up to four devices via individually switchable IEC C13 outlets. With per-port measurement of current, voltage, power, frequency, power factor, and energy consumption, it provides granular insight into power usage. Two sensor ports allow connection of optional temperature, humidity, or air pressure sensors for environmental monitoring. The unit is managed via Ethernet (10/100 Mbit/s) using HTTP/HTTPS, SNMP, Telnet, SSH, Syslog, MQTT, Modbus/TCP, RADIUS, LDAP, and NTP protocols. It supports manual, scheduled, watchdog, sensor-controlled, and remote switching. The metal housing can be used on a desktop, mounted in a 19-inch rack (1U with optional brackets), or on a wall. Input is 100-240V AC via IEC C14 plug, with a maximum total current of 10A and total power of 2300W (at 230V). Security features include user management, SSL/TLS, IP access control, RADIUS, and LDAP. The device consumes approximately 5W and operates in temperatures from 0 to 50 °C.

Advantages

Remote power control and monitoring reduce on-site visits, improve energy efficiency, and enable proactive maintenance. Per-port metering helps identify power-hungry devices and optimize load distribution. Sensor ports allow integration of environmental monitoring for data centers or server rooms. The wide range of management protocols ensures compatibility with existing network infrastructure. Robust security features protect against unauthorized access.

Suitable for

• Data centers and server rooms requiring remote power management
• IT professionals managing critical network equipment
• Facilities needing environmental monitoring alongside power control
• Applications demanding per-outlet energy metering and switching

Key specifications

• Output: 4x IEC C13 (individually switched and metered)
• Input: 1x IEC C14
• Max total current: 10A
• Max total power: 2300W (at 230V)
• Input voltage: 100-240V AC, 50/60 Hz
• Network: 1x Ethernet 10/100 Mbit/s
• Management: HTTP/HTTPS, SNMPv1/v2c/v3, Telnet, SSH, Syslog, MQTT, Modbus/TCP, RADIUS, LDAP, NTP
• Sensor ports: 2x (for optional sensors)
• Mounting: Desktop, 19-inch rack (1U with brackets), wall
• Housing: Metal
• Operating temperature: 0 – 50 °C
• Power consumption: approx. 5W

Recommendations

For optimal performance, use with a UPS and ensure network connectivity. Pair with GüDE temperature/humidity sensors for comprehensive environmental monitoring. The device is ideal for small to medium-sized racks where per-outlet control and metering are required.
