GÜDE Expert Power Control Net D4x 1202 etävirrankatkaisin TCP/IP-verkoille

Managing power distribution across multiple devices in a rack or remote location can be a challenge, especially when equipment hangs or needs a hard reset. The GüDE Expert Power Control Net D4x 1202 solves this by putting four independent power outlets under network control, so you can reboot servers, routers, or other gear from anywhere without physical access.

Who is it for

IT administrators, data center operators, and system integrators who need reliable remote power management for servers, network equipment, or industrial devices. It's ideal for branch offices, server rooms, and distributed installations where on-site intervention is costly or impossible.

Main features

• Four switched IEC C13 outlets, each individually controllable via TCP/IP network
• Integrated energy metering per outlet and total: current, voltage, power, energy, frequency, power factor
• Multiple remote access protocols: HTTP/HTTPS web interface, SNMP v1/v2c/v3, Telnet, SSH, MQTT
• Watchdog function with ping and port monitoring to automatically reboot unresponsive devices
• External sensor port (RJ12) for optional temperature/humidity monitoring and sensor-based switching
• Robust metal housing for desktop, wall, or 19-inch rack mounting (rack kit optional)

Specifications

• Input: 1x IEC C14, 100-240V AC, 10A max
• Output: 4x IEC C13, switched, total switching capacity 2300W at 230V
• Network: Ethernet 10/100 Mbit/s, RJ45, IPv4/IPv6
• Supported protocols: HTTP, HTTPS, SNMP v1/v2c/v3, Telnet, SSH, MQTT, Syslog, NTP, DHCP, DNS, ICMP, ARP, TCP, UDP
• Security: SSL/TLS, SSH, SNMPv3, user management
• Operating temperature: 0 to 50 °C
• Firmware update via web interface

Tips

Pair this unit with GüDE temperature/humidity sensors to create automated environmental control. For rack installations, order the optional 19-inch mounting kit. Use the watchdog feature to monitor critical services and automatically power-cycle devices that stop responding.
