Hager G3139 RJ45 Cat.6 suojattu datapistorasiaosa rintakanavaan

Supporting Gigabit Ethernet with a bandwidth of up to 250 MHz, the Hager G3139 delivers high-speed data transmission in a compact, snap-in module for skirting duct systems.

Overview

The Hager G3139 is a shielded RJ45 data socket insert designed for integration into Hager Tehalit skirting ducts. It provides a single Cat.6 connection point for data networking and VoIP applications, ensuring reliable performance in office and commercial environments.

What stands out

• Cat.6 performance with support for 1000Base-T Gigabit Ethernet
• Shielded design with die-cast zinc housing for EMI protection
• Gold-plated contacts for corrosion resistance and consistent connectivity
• Snap-in mounting for quick installation without tools
• Compatible with Hager Tehalit SL and BR series skirting ducts

Technical details

• Connector type: RJ45 female
• Termination: LSA-compatible IDC terminals
• Wiring standard: TIA/EIA 568A/B
• Module width: 1 module (22.5 mm)
• Colour: Pure White (RAL 9010)
• Housing material: Halogen-free thermoplastic
• Contact material: Gold-plated
• Shielding material: Die-cast zinc

Our verdict

A robust and reliable data outlet for structured cabling in skirting ducts, offering excellent shielding and easy installation for professional network setups.
