Hager TXA114 KNX huonelämpötila-anturi -5...+45 °C IP20 valkoinen

The Hager TXA114 is a high-precision KNX room temperature sensor designed for flush-mounted installation. It accurately measures ambient temperature within a range of -5 to +45 °C and transmits the data to the KNX bus for further processing. With its compact design and reliable performance, it is ideal for modern building automation systems.

Advantages

• High accuracy of ±0.5 K ensures precise temperature control.
• Easy integration into KNX systems via bus terminal.
• Flush-mounted design saves space and blends seamlessly into interiors.
• Low power consumption (max. 5 mA) from KNX bus.
• Durable plastic housing in white (RAL 9010).

Suitable for

• Residential and commercial building automation
• HVAC control systems
• Smart home KNX installations
• Temperature monitoring in offices, hotels, and homes

Key specifications

• Product Type: KNX Room Temperature Sensor
• Bus System: KNX
• Measurement Parameter: Temperature
• Temperature Measurement Range: -5 to +45 °C
• Temperature Accuracy: ±0.5 K
• Ingress Protection (IP) Rating: IP20
• Mounting Type: Flush-mounted (for standard flush-mount box)
• Power Supply: KNX Bus (21-30V DC)
• Current Consumption: Max. 5 mA
• Connection Type: KNX Bus Terminal
• Housing Material: Plastic
• Color: White (RAL 9010)
• Installation Depth: Approx. 12 mm
• Operating Humidity: 5% to 93% RH (non-condensing)
• Configuration Software: ETS (Engineering Tool Software)
• Functions: Temperature value acquisition and transmission to KNX bus
• Display: No
• Certification: CE

Recommendations

For optimal performance, pair the TXA114 with a compatible KNX actuator and configure using ETS software. Ensure proper flush-mount box installation for accurate readings.
