HellermannTyton HIS-PACK-4,8/2,4-CL lämpökutistesukka, 2:1, 4,8 mm - 2,4 mm, läpinäkyvä, 5 kpl x 1,2 m

The HIS-PACK-4,8/2,4-CL from HellermannTyton offers a clear, 2:1 heat shrink tubing solution in a convenient dispenser pack. Unlike bulk tubing, this pack contains five pre-cut 1.2 m lengths, ready for immediate use in electrical insulation, bundling, and strain relief.

Highlights

• Transparent polyolefin construction allows visual inspection of covered connections.
• 2:1 shrink ratio recovers from 4.8 mm to 2.4 mm for a tight, secure fit.
• Supplied in a dispenser box with five 1.2 m pieces for easy storage and handling.
• Operating temperature range from -55°C to +125°C suits a wide range of environments.

In daily use

Slide the tubing over the connection, apply heat above +100°C, and it shrinks to form a durable, insulating sleeve. The clear material lets you inspect the underlying joint without removing the tubing, which is especially useful for prototype work or where visual confirmation is required.

Full specifications

• Material: Polyolefin (PO-X)
• Shrink ratio: 2:1
• Expanded diameter: 4.8 mm
• Recovered diameter: 2.4 mm
• Length per piece: 1.2 m
• Pieces per pack: 5
• Colour: Transparent
• Operating temperature: -55°C to +125°C
• Minimum shrink temperature: +100°C
• Dielectric strength: 20 kV/mm
• Tensile strength: 10.4 MPa
• Elongation at break: 200%
• Volume resistivity: 10^14 Ω·cm
• Water absorption: 0.1% (24h, 23°C)
• Flammability rating: UL94 V2

Final note

A practical choice for professionals needing clear, reliable insulation with the convenience of pre-cut lengths and a dispenser box.
