In today's fast-paced business environment, a slow or unreliable network can cripple productivity. The HP JC90-01606A 24-Port Gigabit Managed Layer 3 Rackmount Switch tackles this problem head-on by delivering high-speed, secure, and easily manageable connectivity for growing networks. This 1U rack-mountable switch provides 24 Gigabit Ethernet ports and 4 shared SFP uplinks, ensuring fast data transfer and flexible fiber connectivity. With full Layer 3 routing capabilities, advanced security features, and robust management options, it is an ideal solution for small to medium-sized businesses, branch offices, and enterprise edge deployments.

Who is it for

This switch is perfect for IT administrators and network engineers who need a reliable, high-performance switch that can handle demanding applications such as VoIP, video streaming, and large file transfers. It suits organizations that require advanced traffic management, VLAN segmentation, and strong security without breaking the budget. Whether you are upgrading an existing network or building a new one, this switch provides the scalability and features needed to support a modern workforce.

Main features

• 24 x 10/100/1000Base-T Gigabit Ethernet ports for high-speed connectivity
• 4 x shared SFP ports for fiber uplinks, offering flexible network design
• Layer 3 static routing, RIP, OSPF, and PIM for efficient traffic routing
• Advanced security: ACLs, port security, RADIUS/TACACS+, SSH, SSL
• Comprehensive management: CLI, web GUI, SNMP, and system event log
• Support for up to 2048 VLANs and jumbo frames up to 9220 bytes
• Switching capacity of 96 Gbps and throughput of 71.4 Mpps
• MAC address table size of 16,000 entries for large network environments
• Optional redundant power supply support for increased reliability
• Rack-mountable 1U form factor for efficient space utilization

Specifications

• Product Type: Managed Network Switch
• Form Factor: Rack-mountable (1U)
• Ethernet Ports: 24 x 10/100/1000Base-T Gigabit Ethernet
• Uplink Ports: 4 x SFP (shared with 4 copper ports)
• Management Type: Fully Managed (CLI, Web GUI, SNMP)
• Layer Support: Layer 3 (Static, RIP, OSPF, PIM)
• Switching Capacity: 96 Gbps
• Throughput: 71.4 Mpps
• MAC Address Table Size: 16,000 entries
• Jumbo Frame Support: Yes (up to 9220 bytes)
• VLAN Support: Yes (up to 2048 VLANs)
• Quality of Service (QoS): Yes
• Security Features: ACLs, Port Security, RADIUS/TACACS+, SSH, SSL
• Power Supply: Internal AC 100-240V
• Redundant Power Supply (RPS) Support: Yes (optional)
• Power over Ethernet (PoE): No
• Processor: Freescale PowerPC 8540 @ 667 MHz
• Memory: 512 MB SDRAM, 4 MB Flash
• Operating Temperature: 0 to 45 °C (32 to 113 °F)
• Humidity Range Operating: 15 - 95% (non-condensing)

Tips

To maximize performance, use Cat6 or higher cabling for Gigabit connections and ensure proper ventilation in the rack. For high-availability setups, consider adding an optional redundant power supply. Regularly update the firmware to benefit from the latest security patches and feature enhancements. Use VLANs to segment traffic and improve security, and leverage QoS to prioritize critical applications like voice and video.
