HPE Aruba 3810M 24SFP+ 250W Managed L3 Stackable -kytkin

The HPE Aruba 3810M 24SFP+ 250W Switch is a high-performance managed L3 stackable switch designed for enterprise networks requiring high-density 10 Gigabit SFP+ connectivity. With 24 SFP+ ports and 2 module slots, it delivers exceptional switching capacity of 640 Gbps and throughput of 380.9 Mpps, making it ideal for demanding applications such as data center aggregation, campus core, and high-speed server access.

Advantages

This switch offers advanced Layer 3 routing protocols including OSPF, BGP, and VRRP, ensuring robust network scalability and redundancy. Its hot-plug power supply and optional redundancy minimize downtime, while features like VLAN, QoS, ACL, and VXLAN provide flexible traffic management and security. The 1U rack-mountable design saves space, and jumbo frame support up to 9220 bytes enhances data transfer efficiency.

Suitable for

• Enterprise campus networks requiring high-density 10GbE
• Data center top-of-rack or aggregation
• High-performance computing environments
• Service provider edge deployments

Key specifications

• 24 x 10 Gigabit SFP+ ports
• 2 module expansion slots
• Switching capacity: 640 Gbps
• Throughput: 380.9 Mpps
• 1 x 250W AC hot-plug power supply (optional redundant)
• 1U rack-mountable
• MAC address table: 64,000 entries
• IPv4 routes: 10,000; IPv6 routes: 5,000
• MTBF: 200,000 hours

Recommendations

For optimal performance, pair with HPE Aruba 3810M stacking modules and SFP+ transceivers. Ensure proper ventilation in the rack and consider a redundant power supply for mission-critical environments.
