Jäähdytyssiili ICY BOX IB-M2HS-PS5 PlayStation 5:lle musta 27 mm x 76 mm x 9 mm

The ICY BOX IB-M2HS-PS5 M.2 heatsink is designed to fit the PlayStation®5 and provides reliable passive cooling for 22 x 80 mm M.2 SSDs. Its compact black aluminium body (27 mm × 76 mm × 9 mm) ensures even heat dissipation to maintain stable performance and reduce the risk of SSD failure during extended gaming sessions. The heatsink is also compatible with standard gaming PCs.

Advantages

The all-aluminium construction provides efficient thermal transfer while keeping weight low. Dimensions are matched to the PS5 form factor for easy installation. Thermal pads and mounting accessories are included, so the M.2 SSD can be coupled directly to the heatsink for optimal heat exchange. The passive design requires no power or moving parts.

Suitable for

• Cooling 22 x 80 mm M.2 NVMe or SATA SSDs
• Upgrading or maintaining PlayStation®5 storage
• Adding a compact heatsink to a gaming PC M.2 slot

Key specifications

• Model: ICY BOX IB-M2HS-PS5
• Type: Heatsink for M.2 SSD (22 x 80 mm)
• Dimensions: 27 mm × 76 mm × 9 mm
• Colour: Black
• Material: Aluminium (all-aluminium body)
• Weight: 0.086 kg
• Manufacturer country: China
• Compatibility: PlayStation®5 and standard gaming PCs

How to use

Turn off and unplug the PlayStation®5 or PC before installation. Remove the M.2 cover and unscrew the M.2 slot if necessary. Clean the SSD surface, place the supplied thermal pad on the SSD, then position the ICY BOX heatsink so it fully contacts the pad and SSD. Secure the assembly using the included mounting accessories and reattach the M.2 cover. Power on the console or PC and verify the drive is recognised.

Recommendations

Install the heatsink on 22 x 80 mm M.2 SSDs only. Ensure thermal pads are correctly placed for full contact between the SSD and the heatsink. Do not block console ventilation; keep the PS5 in a well-ventilated area to maintain overall cooling efficiency.
