JAVEL kolmoispistorasia Schuko lapsisuojalla, 3 moduulia, valkoinen, uppoasennus

The JAVEL Triple Schuko Socket Outlet is a high-quality flush-mounted electrical socket designed for safe and reliable power distribution in indoor dry locations. Featuring three Type F (Schuko) sockets with integrated child protection shutters, this 3-module block is ideal for residential and commercial installations where multiple devices need to be powered from a single point. Manufactured from durable thermoplastic and compliant with PN-EN 60884-1 standards, it offers screw terminal connections for secure wiring and is compatible with standard Ø60mm flush-mount boxes.

Advantages

This triple socket outlet provides three independent power points in a compact horizontal module, saving space and reducing installation complexity. The integrated child protection shutters prevent accidental insertion of foreign objects, enhancing safety in homes with children. The flush-mount design ensures a clean, professional finish, while the high-quality thermoplastic material guarantees long-lasting performance and resistance to wear.

Suitable for

• Residential living rooms, bedrooms, and home offices
• Commercial offices, meeting rooms, and retail spaces
• Indoor dry areas requiring multiple power outlets
• New constructions and renovation projects

Key specifications

• Socket Type: Triple Schuko (Type F)
• Number of Sockets: 3
• Earthing: Yes
• Child Protection: Yes (Integrated Shutters)
• Rated Voltage: 250V AC
• Rated Current: 16A
• Mounting Type: Flush-mounted
• Connection Type: Screw Terminals
• Material: High-quality Thermoplastic
• Color: White
• IP Rating: IP20
• Product Series: Simon Basic
• Standard Compliance: PN-EN 60884-1
• Module Configuration: 3-Module Block
• Orientation: Horizontal
• Recommended Application: Indoor Dry Locations
• Installation Box Compatibility: Standard Ø60mm Flush-Mount Boxes
• Max. Terminal Wire Size: 2.5 mm²

Recommendations

For optimal performance and safety, ensure installation is carried out by a qualified electrician. Use with standard Ø60mm flush-mount boxes and appropriate wiring. This product is designed for indoor use only and should not be exposed to moisture or dust beyond IP20 rating.
