Kotelokehys Rittal GA 9118.700, harmaa, 314 × 214 mm, yksiosainen

Rittal GA 9118.700 is a single-piece enclosure frame in grey with external dimensions of 314 × 214 mm, intended for mounting and protecting electronic modules and components inside control cabinets and equipment housings. The frame provides a stable mounting surface and defined cutout for integrating displays, connectors, switches or small assemblies in industrial and IT installations. Supplied as one unit with a compact footprint and moderate weight suitable for retrofitting or new panel designs.

Advantages

The one-piece construction ensures a consistent alignment and simplified installation without the need for additional joining hardware. The grey finish offers neutral appearance and corrosion-resistant surface treatment suitable for standard indoor industrial environments. Its standardized outer dimensions and flat mounting area enable straightforward integration with front panels, rack units or custom housings, reducing preparation time and minimizing modification of surrounding structures.

Suitable for

Key specifications

How to use

Prepare the panel cutout or enclosure opening to match the frame outer dimensions. Position the frame into the prepared opening, ensuring correct orientation and alignment with any internal mounting points. Secure the frame using appropriate fasteners consistent with the enclosure material and the frame’s mounting provisions. After installing the frame, mount electronic modules, displays or connectors to the frame’s internal mounting area and complete cable routing and grounding as required by the system design.

Recommendations

For reliable operation, use the enclosure frame in indoor, climate-controlled environments and follow applicable installation standards for electrical enclosures. Verify mechanical clearances for components mounted behind the frame and use compatible sealing or gasket materials if environmental protection is required.
