Lanview MO-UF-SM-1G-LH verkkolähetin-vastaanotinmoduuli kuitu 1000 Mbit/s SFP 1310 nm

The Lanview MO-UF-SM-1G-LH is an SFP fiber optic transceiver module designed for 1 Gbit/s network links. Operating at a wavelength of 1310 nm, this compact module provides a reliable interface for single-mode fiber connections. It features a metal housing and conforms to RoHS and MSA standards, making it suitable for integration into existing and future networking equipment.

Advantages

The module supports a data rate of up to 1000 Mbit/s and is built for single-mode fiber operation at 1310 nm. Its metal casing ensures durability and electromagnetic shielding, while compliance with MSA and RoHS standards guarantees interoperability and environmental safety. The compact dimensions (14 mm × 56 mm × 8.5 mm) allow installation in a variety of SFP-compatible ports.

Suitable for

• 1 Gbit/s single-mode fiber links
• Switches and routers with SFP ports
• Enterprise and carrier-grade network uplinks
• Data center fiber connections

Key specifications

• Model: Lanview MO-UF-SM-1G-LH
• Data rate: 1000 Mbit/s (1 Gbit/s)
• Wavelength: 1310 nm
• Media: single-mode fiber
• Housing: metal
• Standards: RoHS, MSA compliant
• Dimensions: 14 mm (W) × 56 mm (D) × 8.5 mm (H)
• MPN: MO-UF-SM-1G-LH
• EAN: 5704174860112

How to use

Insert the SFP transceiver into a compatible SFP port on a switch, router, or media converter, ensuring proper orientation until it locks into place. Connect a single-mode fiber cable with the appropriate connector (LC or as supported by the port). Verify link status and network configuration on connected devices to confirm successful negotiation at 1 Gbit/s.

Recommendations

Use clean, undamaged single-mode fiber and appropriate patch cords; follow ESD precautions when handling the module. Match transceiver wavelength and type at both ends of the link, and ensure devices support SFP modules compliant with MSA for best interoperability.
