LANVIEW Quick Assembly Flat pack 19 6U seinäasennuskaappi (musta)

The LANVIEW Quick Assembly Flat pack 19 is a 19-inch 6U wall mount rack cabinet that combines industrial-grade construction with a space-saving design. Engineered for rapid deployment, this flat-pack unit can be assembled in minutes using minimal tools, making it an ideal choice for IT professionals, system integrators, and AV installers who need reliable equipment housing without complex installation procedures.

Advantages

Quick assembly flat-pack design reduces installation time significantly. The robust cold-rolled steel body with powder-coated finish ensures durability and longevity in demanding environments. The tempered glass front door with lock provides both security and visibility of installed equipment. Removable side panels allow easy access for maintenance and cable management. Top and bottom cable entries keep wiring organised and neat. Passive ventilation with fan cut-outs maintains proper airflow for heat dissipation.

Suitable for

• Network closets and telecom rooms
• Small server rooms and edge computing sites
• Retail back offices and point-of-sale installations
• Audio-visual equipment mounting
• Any location where space is at a premium

Key specifications

• Rack height: 6U
• Rack width: 19 inch
• Mounting type: Wall mount
• Material: Cold rolled steel
• Front door: Tempered glass with lock
• Side panels: Removable with latches
• Cable entry: Top and bottom
• Ventilation: Passive with fan cut-outs
• Max static load capacity: 60 kg
• Colour: Black (RAL 9004)
• Surface finish: Powder coated
• Protection rating: IP20
• External dimensions (W x H x D): 600 x 370 x 450 mm
• Compliance: RoHS, CE
• Included accessories: 2 keys, cage nuts & screws

Recommendations

When mounting the rack, ensure the wall can support the combined weight of the cabinet and installed equipment. For optimal cooling, avoid blocking the ventilation cut-outs and consider installing additional fans if heat load is high. Always use the included cage nuts and screws for secure equipment installation.
