Legrand 412563 2-napainen modulaarinen kontaktori 25 A 230 V AC DIN-kisko

With a rated operational current of 25 A and a 230 V AC coil, this Legrand 412563 modular contactor delivers dependable switching for lighting and heating circuits. Its 2 NO contact configuration and compact 2-module DIN rail housing make it a practical choice for distribution boards.

Overview

The Legrand 412563 is a 2-pole modular contactor designed for AC-1 loads up to 25 A. It features a 230 V AC coil, two normally open contacts, and mounts on a standard 35 mm DIN rail (EN 60715). The unit is rated for 50/60 Hz operation and offers a mechanical endurance of 1,000,000 cycles.

What stands out

• Rated operational current of 25 A (AC-1) for robust load switching.
• Compact 2-module width (35 mm) saves space in enclosures.
• High mechanical endurance of 1,000,000 cycles ensures long service life.
• DIN rail mounting enables quick installation in distribution boards.
• Coil control voltage of 230 V AC matches common mains supplies.

Technical details

• Product type: Modular contactor
• Number of poles: 2
• Contact configuration: 2 NO
• Rated operational current (AC-1): 25 A
• Coil control voltage: 230 V AC
• Frequency: 50/60 Hz
• Mounting type: DIN rail (EN 60715)
• Module width: 2 modules (35 mm)
• Rated insulation voltage (Ui): 500 V
• Rated impulse withstand voltage (Uimp): 4 kV
• Electrical endurance: 100,000 cycles
• Mechanical endurance: 1,000,000 cycles
• Degree of protection: IP20
• Operating temperature range: -25°C to +60°C
• Terminal capacity (flexible): 1.5 - 10 mm²
• Terminal capacity (rigid): 1.5 - 16 mm²
• Power consumption (holding): 1.5 VA
• Power consumption (pull-in): 4.5 VA
• Max switching power (AC-1, 230 V): 5.5 kW

Our verdict

The Legrand 412563 is a reliable and compact modular contactor that meets the demands of residential and light commercial switching applications. Its high endurance and straightforward DIN rail installation make it a solid choice for electricians.
