MEAN WELL RSP-75-15 75W 15V 5A 1U suljettu virtalähde aktiivisella PFC:llä

Industrial and commercial systems often struggle to find a power supply that delivers stable 15V DC output within tight space constraints. The MEAN WELL RSP-75-15 solves this by packing 75W of reliable power into a slim 1U low-profile metal enclosure, making it ideal for rack-mounted equipment, automation controllers, and LED lighting arrays where every millimetre counts.

Who is it for

System integrators, panel builders, and maintenance engineers who need a dependable 15V DC source for industrial electronics, test fixtures, or communication devices. Its wide input range and active PFC make it suitable for both 115V and 230V mains environments, including generator or unstable grid conditions.

Main features

• 75W continuous output at 15V DC with 5A current capability
• Universal AC input: 85–264VAC or 120–370VDC
• Active Power Factor Correction (PFC) for efficient energy use
• High efficiency up to 88%, reducing heat and energy costs
• Free air convection cooling – no fan, no noise, no maintenance
• Comprehensive protections: short circuit, overload, over voltage, over temperature
• 3kVAC isolation between input and output for safety
• Compact 1U height metal case for easy rack integration
• Adjustable output voltage from 13.5V to 18V via built-in potentiometer
• Low ripple & noise (150mVp-p) for sensitive electronics
• Certified to UL60950-1, TUV EN60950-1, CB, and CE standards

Specifications

• Output voltage: 15V DC (adjustable 13.5–18V)
• Output current: 5A
• Rated power: 75W
• Input voltage: 85–264VAC / 120–370VDC
• Efficiency: up to 88%
• Power factor: active PFC
• Operating temperature: -30°C to +70°C
• Cooling: free air convection
• Protections: short circuit, overload, over voltage, over temperature
• Isolation voltage: 3kVAC (input to output)
• Ripple & noise: 150mVp-p
• Leakage current: <1mA at 240VAC
• MTBF: >700,000 hours
• Housing material: metal case
• Form factor: 1U low profile enclosed

Tips

When mounting multiple RSP-75-15 units side by side, leave at least 15mm clearance on all sides for proper convection airflow. For applications with high inrush current at startup, consider using an external soft-start circuit or ensure the upstream breaker is rated accordingly. The output voltage can be fine-tuned via the front-panel potentiometer to compensate for voltage drops in long cable runs.
