METZ CONNECT LC-OS2 simplex kuitu-patchkaapeli, 2 m, vihreä, 20 kpl:n pakkaus

The METZ CONNECT 1509QAJA002C-E is a high-quality LC to LC simplex fiber optic patch cable designed for OS2 single-mode applications. With a length of 2 meters and a green LSZH jacket, this cable ensures reliable, low-loss connections in data centers, telecommunications, FTTx, and LAN environments. The pack contains 20 pieces, making it ideal for bulk installations or network expansions.

Advantages

This patch cable offers exceptional performance with insertion loss ≤ 0.3 dB and return loss ≥ 50 dB, ensuring minimal signal degradation. The 9/125 µm core/cladding diameter and UPC polish provide optimal transmission for single-mode networks. The LSZH jacket enhances safety by reducing toxic fumes in case of fire, while the robust 2.0 mm diameter cable withstands daily use.

Suitable for

• Data center cabling
• Telecommunications infrastructure
• FTTx deployments
• Local area networks (LAN)
• High-speed fiber optic connections

Key specifications

• Fiber Type: OS2 Single-mode
• Connector: LC to LC, Simplex
• Cable Length: 2 meters
• Core/Cladding: 9/125 µm
• Jacket Color: Green
• Connector Polish: UPC
• Insertion Loss: ≤ 0.3 dB
• Return Loss: ≥ 50 dB
• Jacket Material: LSZH
• Cable Diameter: 2.0 mm
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Compliance: RoHS, REACH
• Pack Quantity: 20 pieces

Recommendations

For optimal performance, ensure connectors are clean before installation. This cable is compatible with standard LC interfaces and is suitable for both indoor and controlled outdoor environments. Pair with METZ CONNECT patch panels and adapters for a complete solution.
