MITON MT-P13A pinta-asennettava kotelo, ABS, IP65, harmaa (RAL 7035)

The MITON MT-P13A is a robust surface mount electrical enclosure designed for indoor and outdoor applications. Manufactured from high-quality ABS plastic, it offers excellent durability and protection against environmental factors. With an IP65 rating and IK07 impact resistance, this enclosure is dustproof and water-jet proof, making it suitable for demanding environments.

Advantages

This enclosure provides reliable protection for electrical components, ensuring long-term performance. Its UV-resistant and halogen-free materials make it safe for use in various settings. The smooth wall design allows for custom cable entries, offering flexibility during installation.

Suitable for

• Electrical junction boxes
• Distribution boards
• Control enclosures
• Outdoor installations

Key specifications

• Product Type: Electrical Enclosure
• Mounting Type: Surface Mount
• Material: ABS Plastic
• IP Rating: IP65
• Impact Resistance: IK07
• External Dimensions (L x W x H): 130 x 130 x 70 mm
• Internal Dimensions (L x W x H): Approx. 122 x 122 x 65 mm
• Color: Grey (RAL 7035)
• Lid Type: Solid, Screw-on
• Number of Lid Screws: 4
• Operating Temperature Range: -25°C to +60°C
• Flammability Rating: UL94-V2
• Halogen-Free: Yes
• UV Resistance: Yes
• Gasket Material: Polyurethane (PU)
• Standards Compliance: CE, RoHS

Recommendations

For optimal installation, ensure proper cable entry sealing to maintain IP65 protection. Suitable for use with standard electrical components.
