MULTISWITCH SMART LINE 9/24 CORAB

The CORAB MULTISWITCH SMART LINE 9/24 is a high-performance multiswitch designed for distributing satellite and terrestrial TV signals to up to 24 subscribers. It supports 8 satellite inputs and 1 terrestrial input, making it ideal for multi-dwelling units or small hotels. With DiSEqC 2.0 protocol compatibility and built-in power supply, this unit ensures reliable signal distribution with minimal loss.

Advantages

This multiswitch offers excellent signal isolation and low power consumption, ensuring stable operation. Its wall-mountable metal housing provides durability and easy installation. The built-in power supply simplifies setup, eliminating the need for external adapters.

Suitable for

• Multi-dwelling buildings (apartments, condos)
• Small hotels and guesthouses
• Commercial installations requiring up to 24 outputs
• Satellite TV distribution systems using Quattro LNBs

Key specifications

• 8 satellite inputs, 1 terrestrial input, 24 subscriber outputs
• Satellite frequency range: 950-2150 MHz
• Terrestrial frequency range: 47-862 MHz
• Satellite subscriber gain: 0 dB (±2 dB)
• Terrestrial subscriber gain: -15 dB (±2 dB)
• Max. satellite output level (IMD3 -35dB): 95 dBµV
• Max. terrestrial output level (IMD3 -60dB): 85 dBµV
• Satellite input isolation (H/V): >30 dB
• Terrestrial to satellite isolation: >30 dB
• Switching protocol: DiSEqC 2.0 (compatible with 1.0, 1.1)
• LNB power supply: 18V DC, max 500mA
• Power supply: Built-in 230V AC, 50Hz
• Power consumption: <10 W (without LNBs)
• Operating temperature: -20 to +50 °C
• Housing material: Metal
• Mounting type: Wall-mountable

Recommendations

For optimal performance, use with Quattro LNBs and ensure proper grounding. This multiswitch is not cascadable. Ideal for new installations or upgrades in multi-subscriber environments.
