Paikkalaajennin Intel CYP2URISER1STD

Riser card for Riser Slot #1 designed for Intel server systems and server boards. The Slot Expander Intel CYP2URISER1STD increases available PCIe expansion options for compatible servers, enabling additional full-height and half-length cards in the system. It is intended for use with specific Intel® Server Systems and Server Boards to expand I/O and accelerator capacity.

Advantages

The CYP2URISER1STD provides support for multiple PCIe cards from a single riser slot, allowing one full-height/full-length card in the top slot, one full-height/full-length card in the middle slot, and one full-height/half-length card in the bottom slot. The unit is compatible with designated Intel server systems and server boards and carries ECCN EAR99, making it suitable for a range of enterprise and data center environments that require reliable expansion.

Suitable for

• Adding PCIe expansion cards to Intel® Server Systems M50CYP2UR208 and M50CYP2UR312
• Expanding I/O or accelerator cards on Intel® Server Boards M50CYP2SB1U and M50CYP2SBSTD
• Upgrading server capacity where additional full-height or half-length PCIe cards are needed

Key specifications

• Model: Intel CYP2URISER1STD (MPN: CYP2URISER1STD)
• EAN: 5032037210133
• Riser slot supported: Riser Slot #1 only
• Slot layout supported: Slot 1 (top) — one full-height/full-length single; Slot 2 (middle) — one full-height/full-length single; Slot 3 (bottom) — one full-height/half-length single
• Compatibility: Intel® Server Systems M50CYP2UR208, M50CYP2UR312; Intel® Server Boards M50CYP2SB1U, M50CYP2SBSTD
• ECCN: EAR99

How to use

Install the riser card into Riser Slot #1 on the compatible Intel server board or system following the server manufacturer’s installation instructions. After seating the riser, install PCIe cards into the supported top, middle, and bottom slots according to their physical size: full-height/full-length cards in the top and middle slots and a full-height/half-length card in the bottom slot. Secure cards and verify connections before powering on the system.

Recommendations

Use only with the listed Intel server systems and server boards to ensure mechanical and electrical compatibility. Verify card dimensions and power requirements for installed PCIe cards to avoid clearance or power issues. Follow server documentation for proper installation and handling of riser assemblies.
