SAS-kaapeli Intel CYPCBLSL208KIT

The Intel CYPCBLSL208KIT is a set of SlimSAS splitter cables for the M50CYP2UR208 2U system, designed to enable PCIe NVMe storage connectivity. The kit provides multiple length-matched splitter cables that route CPU SlimSAS ports to HSBP SlimSAS SSD connectors, ensuring proper physical connections between the server board and NVMe drive backplane.

Advantages

The cable kit is compatible with the M50CYP2UR208 system and supports SlimSAS connections for PCIe NVMe storage. It includes length-optimized splitters to simplify internal routing in a 2U chassis and to reduce cable congestion. The assembly is intended to maintain signal integrity for high-speed storage links and to provide a straightforward connection layout between CPU SlimSAS ports and HSBP SlimSAS SSD channels.

Suitable for

• Enabling PCIe NVMe drives in 2U Intel M50CYP2UR208 servers
• Connecting server board CPU SlimSAS x4 ports to HSBP SlimSAS SSD connectors
• Data-centre or rack-mounted systems requiring internal SlimSAS routing

Key specifications

• Brand: INTEL
• MPN: CYPCBLSL208KIT
• EAN: 5032037213097
• Compatible system: M50CYP2UR208 (2U)
• Included cables and approximate lengths (splitter ends):
  • 240/260 mm splitter: server CPU0 x4 SlimSAS A/B (VT) to HSBP x8 SlimSAS SSD0-1 (VT)
  • 330/310 mm splitter: server CPU0 x4 SlimSAS C/D (VT) to HSBP x8 SlimSAS SSD2-3 (VT)
  • 235/215 mm splitter: server CPU1 x4 SlimSAS C/D (VT) to HSBP x8 SlimSAS SSD6-7 (VT)
  • 370/390 mm splitter: server CPU1 x4 SlimSAS A/B (VT) to HSBP x8 SlimSAS SSD4-5 (VT)
• Connector type: SlimSAS (internal)
• Purpose: route CPU SlimSAS x4 ports to HSBP x8 SlimSAS SSD channels for PCIe NVMe

How to use

Install the kit inside the M50CYP2UR208 2U chassis by connecting each splitter cable from the designated server board CPU SlimSAS x4 port (A/B/C/D) to the corresponding HSBP x8 SlimSAS SSD connector as indicated. Match the cable lengths and routing to the internal layout to minimize strain and avoid interference with airflow or other components. Ensure connectors are fully seated and secured before powering the system.

Recommendations

Use these SlimSAS splitters only in the compatible M50CYP2UR208 configuration and follow the server manufacturer's installation guidance. Avoid excessive bending or pulling of the cables and verify connector alignment to preserve signal integrity for PCIe NVMe links.
