Solvian akun erotuskytkin 12-32V 500A IP66

The Solvian 3002 Battery Disconnect Switch is a heavy-duty rotary master disconnect designed for reliable power isolation in marine, RV, automotive, and heavy equipment applications. With a continuous current rating of 500A and an intermittent rating of 2500A for 5 seconds, it ensures safe and efficient operation. The IP66-rated housing provides protection against dust and water jets, making it suitable for harsh environments.

Advantages

High current capacity with low voltage drop (<50mV at 500A) ensures minimal power loss. UV-resistant ABS plastic housing and tinned copper terminals offer long-lasting durability. Easy 2-bolt mounting simplifies installation.

Suitable for

• Marine battery systems
• RV and camper electrical systems
• Automotive auxiliary batteries
• Heavy equipment and industrial machinery

Key specifications

• Operating Voltage: 12-32V DC
• Continuous Current: 500A
• Intermittent Current: 2500A (5 seconds)
• IP Rating: IP66
• Switch Type: Rotary Master Disconnect (SPST)
• Number of Positions: 2 (ON/OFF)
• Terminal Stud Size: M10
• Mounting: Surface Mount
• Housing Material: UV-Resistant ABS Plastic
• Terminal Material: Tinned Copper
• Operating Temperature: -30°C to +60°C
• Dielectric Strength: 1500V AC (1 minute)
• Compliance: CE, RoHS

Recommendations

For optimal performance, use with appropriate cable lugs and ensure proper torque on terminal studs. Suitable for both positive and negative battery disconnection.
