SYNERGY21 kuituverkkokaapeli 15m OM3 LC-SC duplex LSZH sininen

The SYNERGY21 S216297 is a high-performance fiber optic patch cable designed for reliable data transmission in demanding network environments. With a length of 15 meters and OM3 multimode fiber, this cable supports high-speed applications up to 10 GbE and beyond. The LC to SC duplex connectors ensure secure connections, while the blue LSZH jacket provides safety and durability.

Advantages

This cable offers low insertion loss and high return loss, ensuring minimal signal degradation. The LSZH jacket reduces toxic fumes in case of fire, making it ideal for indoor installations. The 50/125 µm core/cladding diameter is optimized for multimode applications.

Suitable for

• Data centers
• Local Area Networks (LANs)
• Storage Area Networks (SANs)
• Telecommunications

Key specifications

• Cable Type: Fiber Optic Patch Cable
• Fiber Mode: Multimode
• Fiber Class: OM3
• Connector A: LC Duplex
• Connector B: SC Duplex
• Cable Length: 15 m
• Jacket Color: Blue
• Core/Cladding Diameter: 50/125 µm
• Maximum Data Rate (10GbE): 300 m
• Maximum Data Rate (40GbE/100GbE): 100 m
• Insertion Loss (Typical): < 0.3 dB per connector
• Return Loss (Typical): > 20 dB
• Jacket Material: LSZH
• Cable Construction: Duplex (2 Fibers)
• Ferrule Material: Zirconia Ceramic
• Operating Temperature: -20°C to 70°C
• Compliance: RoHS, CE

Recommendations

For optimal performance, ensure connectors are clean before installation. This cable is compatible with standard LC and SC interfaces.
