Triton ROPAM kosketusnäppäimistö TK-4W

The Triton ROPAM Touch Keypad TK-4W is a capacitive touch keypad designed for seamless integration with ROPAM alarm control panels. Featuring a 2x16 character LCD display and backlit keys, it provides clear system status and easy arming/disarming. The keypad communicates via a 4-wire RS-485 bus and is powered directly from the control panel (12V DC). Its sleek white ABS housing and surface-mount design make it suitable for modern security installations.

Advantages

Capacitive touch technology ensures reliable, noiseless operation with a modern aesthetic. The built-in buzzer and LED indicators (ARM, FAULT, POWER) provide immediate system feedback. Tamper protection against opening and detachment enhances security. A programmable zone input and OC-type output offer flexibility for custom configurations.

Suitable for

• ROPAM OptimaGSM, NeoGSM, MultiGSM, BasicGSM, and VSR-2 alarm control panels
• Residential and commercial security systems requiring a user-friendly keypad
• Surface-mounted wall installations

Key specifications

• Keypad Type: Capacitive Touch
• Display: LCD, 2x16 characters
• Communication: RS-485 Bus (4-wire)
• Power Supply: 12V DC (from control panel)
• Current Consumption: Standby ~30 mA, Max ~80 mA
• Backlight: Keys and Display
• Tamper Protection: Yes (against opening and detachment)
• Programmable Zone Input: 1 (NO/NC)
• Programmable Output: 1 (OC type, 100mA max)
• Built-in Buzzer: Yes
• Housing Material: ABS Plastic
• Color: White
• Operating Temperature: -10°C to +55°C
• Mounting: Surface-mounted (Wall)
• Key Functions: Arm/Disarm, System Status, Event Log, Programming, Quick Arming
• LED Indicators: ARM, FAULT, POWER
• Firmware Update: Via control panel

Recommendations

For optimal performance, pair with a compatible ROPAM control panel. Ensure proper wiring of the RS-485 bus and configure the keypad via the panel's programming interface. The tamper switch should be securely mounted to prevent false alarms.
