ROPAM IOE-IQPLC järjestelmäliitin 10-pin IDC naaras IQPLC-ohjaimelle

The ROPAM IOE-IQPLC System Connector is a high-quality 10-pin IDC female connector designed for system bus interconnection in ROPAM IQPLC controller and IOE expansion module setups. It ensures reliable data and power transmission in industrial automation environments.

Advantages

Gold-plated contacts for corrosion resistance and stable signal integrity. Rated for 1A per pin and 250V AC/DC, suitable for demanding applications. Durable PBT housing withstands -25°C to +70°C operating temperatures.

Suitable for

• ROPAM IQPLC Controllers
• ROPAM IOE Expansion Modules
• Industrial automation system bus interconnection

Key specifications

• Product Type: System Connector
• Connector Type: IDC (Insulation Displacement Connector)
• Number of Pins: 10-pin
• Pin Pitch: 2.54 mm
• Connector Gender: Female
• Cable Type: Flat Ribbon Cable
• Mounting Type: Cable Mount
• Housing Material: PBT
• Contact Material: Copper Alloy
• Contact Plating: Gold over Nickel
• Current Rating: 1 A per pin (max)
• Voltage Rating: 250 V AC/DC (max)
• Operating Temperature: -25°C to +70°C
• Insulation Resistance: 1000 MΩ min at 500V DC
• Dielectric Withstanding Voltage: 500V AC for 1 minute
• Durability: 50 mating cycles
• Color: Black
• RoHS Compliant: Yes

Recommendations

For optimal performance, use with ROPAM IQPLC controllers and IOE expansion modules. Ensure proper cable alignment when terminating.
