WAGO 2001-1204 4-johtimen Push-in CAGE CLAMP -liitinlohko, harmaa, 500V, 24A, 0,25-2,5 mm², DIN-kiskoasennus

The WAGO 2001-1204 is a high-quality 4-conductor terminal block from the 2001 Series, designed for reliable and maintenance-free wiring in industrial and building installations. Featuring the innovative Push-in CAGE CLAMP® connection technology, it enables fast and tool-free connection of solid conductors, while stranded conductors can be connected using a ferrule. This terminal block is ideal for use in control cabinets, junction boxes, and distribution boards.

Advantages

Push-in CAGE CLAMP® technology allows for direct insertion of solid conductors without tools, saving installation time. The compact design saves space on the DIN-rail. The side-entry wiring orientation simplifies wiring in tight spaces. The terminal block is vibration-proof and maintenance-free, ensuring long-term reliability.

Suitable for

• Industrial control systems
• Building automation
• Power distribution
• Machine wiring

Key specifications

• Connection Technology: Push-in CAGE CLAMP®
• Number of Conductors: 4
• Number of Potentials: 1
• Nominal Voltage (EN 60947-7-1): 500 V
• Rated Voltage (UL): 600 V
• Nominal Current (EN 60947-7-1): 24 A
• Connectable Conductor Size (Solid): 0.25 - 2.5 mm² (22 - 14 AWG)
• Connectable Conductor Size (Stranded): 0.25 - 2.5 mm² (22 - 14 AWG)
• Connectable Conductor Size (Fine-Stranded w/ Ferrule): 0.25 - 1.5 mm² (22 - 16 AWG)
• Strip Length: 9 - 11 mm (0.35 - 0.43 inch)
• Mounting Type: DIN-rail (35 x 15 mm / 35 x 7.5 mm)
• Insulation Material: Polyamide 66 (PA 66)
• Color: Gray
• Pollution Degree: 3
• Rated Surge Voltage: 6 kV
• Operating Temperature: -35 to +85 °C
• Wiring Type: Side-entry wiring
• Dimensions (W x H x D): 4.2 mm x 48.5 mm x 32.9 mm

Recommendations

For optimal performance, use with WAGO marking strips and accessories. Ensure proper conductor stripping length (9-11 mm) for reliable connection. Suitable for use in environments with pollution degree 3.
