WAGO 2002-1391 pääty- ja välilevy, harmaa, 0,8 mm paksu

The WAGO 2002-1391 is a high-quality 2-conductor jumper designed for use with WAGO TOPJOB® S (2002 Series) terminal blocks. This jumper enables efficient and reliable electrical connections in control cabinets and industrial applications. With a conductor thickness of 0.8 mm and a length of 32.9 mm, it is engineered for secure push-in installation, ensuring a vibration-resistant and maintenance-free connection.

Advantages

• Time-saving push-in connection technology eliminates the need for tools.
• Compact design saves space in control cabinets.
• High rated voltage (800 V) and current (32 A) for demanding applications.
• Tin-plated electrolytic copper conductor ensures excellent conductivity and corrosion resistance.
• Polyamide 66 insulation with UL 94 V-0 flammability rating for safety.

Suitable for

• Industrial control systems
• Building automation
• Power distribution
• Machine building

Key specifications

• Jumper Type: 2-Conductor Jumper
• Number of Poles: 2
• Compatibility: WAGO TOPJOB® S (2002 Series)
• Connection Method: Push-in
• Rated Voltage: 800 V
• Rated Current: 32 A
• Conductor Material: Electrolytic Copper, Tin-plated
• Insulation Material: Polyamide 66 (PA 66)
• Color: Light Gray
• Mounting Type: Plug-in
• Pitch: 5.2 mm
• Operating Temperature: -35 °C to +105 °C
• Flammability Rating: UL 94 V-0
• Approvals: UL, CSA, VDE, KEMA/KEUR, GL
• Conductor Thickness: 0.8 mm
• Length: 32.9 mm

Recommendations

For optimal performance, use with WAGO TOPJOB® S 2002 Series terminal blocks. Ensure proper insertion to achieve a secure and reliable connection. This jumper is ideal for bridging adjacent terminals in multi-level applications.
