WAGO 2002-1492 pääty- ja välilevy, oranssi, 0,8 mm paksu

The WAGO 2002-1492 is a high-quality jumper designed for use with WAGO 2002 Series terminal blocks. It provides a reliable and secure electrical connection between adjacent terminals, simplifying wiring and reducing installation time. With a pin diameter of 0.8 mm and a length of 32.9 mm, this jumper is ideal for creating potential bridges in control cabinets and junction boxes.

Advantages

This jumper offers several benefits: it ensures a stable and low-resistance connection, reduces wiring errors, and saves space by eliminating the need for additional wiring. The plug-in mounting type allows for quick and easy installation without tools. Made from high-quality materials, it provides long-lasting performance and resistance to environmental factors.

Suitable for

• Industrial control systems
• Building automation
• Electrical distribution panels
• Any application requiring potential bridging in WAGO 2002 Series terminal blocks

Key specifications

• Product Type: Jumper
• Number of Potentials: 1
• Number of Connections: 2
• Number of Jumper Positions: 2
• Rated Voltage (EN): 800 V
• Rated Surge Voltage: 8 kV
• Rated Current (EN): 24 A
• Pin Diameter: 0.8 mm
• Pitch/Spacing: 5.2 mm
• Insulation Material: Polyamide (PA 66)
• Contact Material: Electrolytic Copper, Tin-plated
• Color: Gray
• Mounting Type: Plug-in
• Operating Temperature: -35 to +105 °C
• Flammability Rating: UL 94 V-0

Recommendations

For optimal performance, use this jumper with WAGO 2002 Series terminal blocks. Ensure proper insertion to maintain rated electrical specifications. Suitable for use in environments within the specified temperature range.
