AMEWI AMXRacing AM2230SG PRO analoginen servo teräsvaihteella (28451)

High-torque analog servo engineered for RC models, delivering 25 kg/cm of force at 6.0V with a coreless motor and steel gear train for durability. The AMEWI AMXRacing AM2230SG PRO offers precise control and reliable performance in demanding applications.

Advantages

Steel gears provide exceptional strength and wear resistance, while the coreless motor ensures fast response and smooth operation. Double ball bearings reduce friction and enhance precision, and the 25T spline is compatible with Futaba arms. A wide 4.8V–6.0V operating range offers flexibility.

Suitable for

• 1/8 and 1/10 scale RC cars and trucks
• RC boats requiring high torque steering
• RC planes with standard servo mounts
• Robotics and industrial projects needing reliable actuation

Key specifications

• Servo type: Analog
• Gear material: Steel
• Motor type: Coreless
• Operating voltage: 4.8V – 6.0V
• Torque: 22 kg/cm @ 4.8V, 25 kg/cm @ 6.0V
• Speed: 0.18 sec/60° @ 4.8V, 0.16 sec/60° @ 6.0V
• Bearing: Double ball bearing
• Spline: 25T (Futaba compatible)
• Connector: JR/Futaba compatible
• Housing: Plastic

Recommendations

Pair with a 6.0V BEC or receiver battery to unlock maximum torque. For heavy-duty steering, ensure your servo saver is properly adjusted to protect the steel gears.
