BCS BCS-F-AT01 2MP IR Bullet kamera, 2,8mm, IP66, valkoinen

The BCS BCS-F-AT01 is a high-performance 2 Megapixel IR bullet camera designed for reliable outdoor surveillance. Featuring a 1/2.7" CMOS sensor and switchable video output (AHD/TVI/CVI/CVBS), this camera delivers crisp 1080p resolution at 25/30 fps. With 18 IR LEDs providing up to 20 meters of night vision and an IP66-rated weatherproof housing, it ensures clear monitoring in various lighting and weather conditions. The fixed 2.8mm lens offers a wide field of view, making it ideal for residential, commercial, and industrial security applications.

Advantages

This camera offers exceptional versatility with support for multiple analog HD formats, allowing easy integration into existing CCTV systems. The digital WDR and 2DNR technologies enhance image quality in challenging lighting, while the auto ICR function ensures seamless day/night switching. Its compact, durable plastic housing with IP66 protection makes it suitable for both indoor and outdoor use.

Suitable for

• Outdoor perimeter surveillance
• Parking lots and entrances
• Warehouse and factory monitoring
• Retail stores and offices
• Home security

Key specifications

• Image Sensor: 1/2.7" CMOS
• Resolution: 2 MP (1920x1080)
• Video Output: AHD / TVI / CVI / CVBS (switchable)
• Lens: Fixed 2.8mm
• IR Range: Up to 20m (18 IR LEDs)
• Minimum Illumination: 0.01 Lux (color), 0 Lux with IR
• Day/Night: Auto (ICR) / Color / B/W
• Noise Reduction: 2DNR
• WDR: Digital WDR (DWDR)
• Power: DC 12V, max 4.2W
• Housing: Plastic, IP66
• Operating Temperature: -10°C to +50°C
• Mounting: Ceiling/Wall
• Color: White

Recommendations

For optimal performance, use a regulated DC 12V power supply and ensure proper cable connections. The camera supports OSD menu for easy configuration. Ideal for users seeking a cost-effective, reliable analog HD surveillance solution.
